The HJS H610-I All in one industrial control motherboard is designed based on Intel Alder Lake platform and adopts the Intel H610 chipset.
It supports Intel 12th- 14th Gen Core desktop i3, i5 and i7 processors.The motherboard is equipped with a built-in hardware one-key recovery function.It integrates the RTL8111 Gigabit Ethernet controller, ensuring stable and smooth network performance.
It also supports centralized control, customized management and synchronous transmission of multimedia content via network.The onboard RTL8111 Gigabit network card and RTL8613 Super I/O chip realize RS232 serial port communication and fan speed regulation.
With abundant external interfaces, the motherboard can easily meet the requirements of various software applications.
Product Specification
|
Processor |
Support Intel Core series 12th Gen desktop I3 I5 I7 CPU |
|
Model |
HJS H610-I |
|
Chipset |
Intel H610 |
|
Type |
All-in-one/mini PC industrial control motherboard |
|
Memory |
Single channel SODIMM DDR4 supports up to 32GB |
|
Storage |
1*standard 7Pin SATA female connector and M.2 2280 solid state drive interface |
|
Display Interface |
1*HDMI. female Type-A 3840*2160@60Hz |
|
1*HDMI pin interface (2x8) supports 3840*2160@60Hz |
|
|
1*standard female VGA 1920*1080@60Hz |
|
|
1*EDP. 2*15Pin 2.0mm. Double row pin 1920*1080@60Hz |
|
|
1*LVDS. 2*15Pin 2.0mm. Double row pin 1920*1080@60Hz |
|
|
USB |
4*USB3.0 female Type-A |
|
4 sets of USB2.0. 2*5Pin 2.54mm double row pins |
|
|
Network |
Onboard RTL8111 Gigabit network card, a standard RJ45 interface 10M/100M/1000M adaptive |
|
M.2 2230WIFI interface, supports 2.4G/5G double frequency WIFI |
|
|
Audio |
Onboard RTL ALC897 HD sound card, audio output (green) Mic input (pink). Front panel pin 1 pc |
|
2*5Pin 2.54mm double row pin, 8 ohm 5W speaker output 1 pc 4Pin 2.0mm white socket |
|
|
COM Ports |
1*2*5Pin 2.54mm double row pin (RS232) |
|
Extensions |
M.2 2230 Wifi interface.SATA hard disk interface |
|
Fan |
2*4-pin black sockets (1 IO speed control, 1 fixed speed) |
|
Power supply requirements |
3.5mm DC-IN socket 12V/120W adapter input /ATX 4Pin power socket 12V@10A power input |
|
Button |
1*GHOST button |
|
Size |
170mmX170mm |
