The H510-I AIO industrial control motherboard is designed based on the Intel 10th and 11th Gen Core desktop CPU platform. It adopts the Intel H510 Chipset, supporting Intel 10th and 11th Gen Core desktop processors.
Built on 10nm and 14nm manufacturing processes, Intel 10th/11th Gen Core CPU deliver improved performance, lower power consumption and excellent overclocking capability.Integrated new branch prediction instructions enhance front-end processing and overall operation speed.
Equipped with an upgraded 8th-generation VR power regulation module, the board optimizes internal CPU power management, strengthens power supply stability and further reduces energy consumption.The motherboard features a hardware one-key recovery function.
Onboard RTLALC897 audio chip supports multi-channel high-fidelity audio output.Onboard RTL8111 Gigabit Ethernet adapter enables centralized control, dedicated management and synchronous transmission of multimedia data via network. Onboard IT8613 Super IO chip realizes RS232 serial port function and fan speed regulation. With abundant external interfaces, this motherboard is fully compatible with various application software and effectively improves working efficiency.
Product Specification
|
Processor |
Support Intel Core series 10th Gen desktop I3 I5 I7 CPU |
|
Model |
HJS H510-I |
|
Chipset |
Intel H510 |
|
Type |
All-in-one/ mini PC industrial control motherboard |
|
Memory |
Single channel SODIMM DDR4 supports up to 32GB |
|
Storage |
1*standard 7Pin SATA female connector and M.2 2280 solid state drive interface |
|
Display Interface |
1*HDMI female Type A 3840*2160@60Hz (11th generation CPU) |
|
1*HDMI pin interface (2x8) supports 3840*2160@60Hz (11th generation CPU) |
|
|
1* female standard VGA 1920*1080@60Hz |
|
|
1*EDP 2*15Pin2.0mm double row pin 1920*1080@60Hz |
|
|
1*LVDS 2*15Pin2.0mm double row pin 1920*1080@60Hz |
|
|
USB |
4*USB3.0 female Type-A |
|
4 sets of USB2.0 2*5Pin 2.54mm double-row pins |
|
|
Network |
On board RTL8111 Gigabit network card, one standard RJ45 interface 10M/100M/1000M adaptive |
|
M.2 2230 WIFI interface, supports 2.4G/5G dual-band WIFI, onboard 2.4G/5G WiFi+Bluetooth |
|
|
Audio |
Onboard RTL ALC897 high-definition sound card, audio output (green) and Mic input (pink). 1 front panel pin |
|
2*5Pin 2.54mm double-row pin, 8 ohm 5W speaker output 1 4Pin 2.0mm white socket |
|
|
COM Ports |
1*2*5Pin 2.54mm double row pin (RS232) |
|
Extensions |
M.2 2230 Wifi interface.SATA hard disk interface |
|
Fan |
2*4-pin black sockets (1*IO speed control, 1* fixed speed) |
|
Power supply requirements |
3.5mm DC-IN socket 12V/120W~19V/120W adapter input/ATX4Pin power socket 12V@10A power supply input |
|
Button |
1*GHOST button |
|
Size |
170mmX170mm |
