* Support Intel 12/13th generation Core i3 i5 i7 and Alder Lake-N (N95 N97 N100) series CPU.
* Front HDMI+DP+Type-C display interface.
* Mainboard LPDDR5 memory, support up to 16G.
* 1*standard 7Pin SATA female connector and M.2 2280 solid state drive.
* TheType-C port support video display and fast charging.
* The motherboard support hardware one-key restore/ Network wake-up /scheduled boot and Automatic start function.
Share This Items :
| Product Model | Intel 12/13th gen NUC | ||
| Processor | Support Intel 12/13th generation Core i3 i5 i7 and Alder Lake-N (N95 N97 N100) series CPU | ||
| RAM | Mainboard LPDDR5 memory, supports up to 16GB | ||
| Storage | 1 M.2 2280 solid-state drive interface (supports SATA/NVME protocol) | ||
| Display Interface | 1 HDMI Type-A , 3840*2160@60Hz | ||
| 1 DP Type-A , 3840*2160@60Hz | |||
| 1 Type-C ,3840*2160@60Hz (supports external charging and USB3.0 transmission function) | |||
| USB | 4* USB3.0 Type-A | ||
| 2* USB2.0 Type-A | |||
| 1* Type-C, Supports USB3.0 transmission and video display output (supports external charging function) | |||
| Network | Onboard RTL8111 Gigabit network card, a standard RJ45 interface 10M/100M/1000M adaptive | ||
| M.2 2230 WIFI interface, supports 2.4G/5G dual-band WIFI | |||
| Audio | Onboard RTL ALC897 HD sound card, 2-in-1 headphone jack | ||
| Wireless charging | Support wireless charging | ||
| Fan | 1 4-pin socket (1 IO speed control) | ||
| Power supply requirements | Provides a standard DC-IN socket, 12V/60W or above adapter input | ||
| Button | 1 lighted switch button | ||
| Product size | 102x102x44.6MM | ||
